Core positioning
D-Bees Normal 1080P HD HDMI cable is specially designed to solve the problem of mixed audio-visual system configuration. It utilizes a 18Gbps lossless bandwidth to break through the audio-visual barriers of three scenarios: Projection screens, Starry sky ceilings, and Wooden audio-visual cabinets. Its military-grade terminal structure can withstand 5000 plug-ins and unplugs, meeting the frequent debugging requirements of commercial spaces.
Hardcore parameter system
• Transmission standard: HDMI 2.0 protocol (compatible with HDR10+)
• Cable structure: 28AWG four-layer shielded copper core
• Transmission loss: Signal attenuation ≤ 0.5dB within 15 meters
• Bend radius: 8mm dynamic flexible outer sheath
• Interface coating: 50μinch gold-plated anti-oxidation
Technical breakthrough
Intelligent impedance compensation
The dynamic adjustment module enables the color depth of the 3D projection system to be stabilized at 12 bits. When used with 4K-level Projection screens, the smoothness of the gray-scale transition is improved by 62%.
Full-scene compatibility
The 32-bit signal processor is compatible with Dolby Atmos panoramic sound and DTS:X dual decoding, achieving a signal distortion rate of 0.05% in the wooden acoustic-visual cabinet.
Anti-interference matrix
A four-layer aluminum foil + woven mesh shielding structure, in the LED-dense "Starry sky" ceiling environment, the signal-to-noise ratio remains above 72 dB.
Strict scene verification
1. Immersive exhibition hall: The synchronization error of 8 groups of Projection screens is less than 0.3 frames simultaneously
2. Starry sky lounge: The DMX512 control signal of the Starry sky ceilings has zero crosstalk
3. Private cinema: 20-meter lossless transmission is achieved within the wooden audio-visual cabinet of the wooden cavity
The value behind the parameters
A case study of a certain cinema chain shows:
1. The transmission distance of 4K HDR picture quality has exceeded 22 meters (industry average is 12 meters)
2. The failure rate of equipment compatibility has decreased by 89%
3. Annual cost savings for wire replacement have reached 470,000 yuan
Real user testimony
"This is the most intelligent HDMI solution we have ever debugged," commented a technical director of an immersive theater. "Under the electromagnetic interference of the laser Starry sky ceilings, the color accuracy ΔE value remained stable within 1.2." In a high-end residential project, this cable successfully achieved 4:4:4 chroma sampling over a 26-meter transmission distance, breaking through the physical limitations of the wooden audio-visual system.
Military-grade craftsmanship
► Salt spray resistance test for injection molded terminals: 1200 hours without oxidation (IEC 60068-2-11)
► Tensile strength of wire: 80kg static load test (far exceeding the 35kg standard on the market)
► Thermal cycling durability: -20℃ to 80℃ extreme temperature test for 200 cycles
Value-added features highlights
▶ Hot-swappable protection: 6000V surge protection design to eliminate the risk of damage
▶ Directional memory chip: Intelligent adaptation for transmitting and receiving ends
Commercial value transformation
Actual test results of a theme hotel renovation case:
• Equipment debugging time was reduced from 6 hours to 45 minutes
• 4K video playback lag rate dropped from 17% to 0.4%
• Cable service life exceeded 8 years (average 3 years for ordinary products)
Special Adaptation Plan
Star Sky Meeting System:
Achieves protocol-level compatibility with the DMX512 controller of Starry Sky Ceilings
The color accuracy synchronization deviation of the RGBW four-channel light source is ≤ 1.5%
Wooden Audio-Visual System:
Developed low magnetic flux version cables for the Wooden audio-visual cabinet
The signal transmission stability is improved by 32%
Gigantic Projection Array:
Supports 12 groups of Projection screens in a daisy chain synchronous control
The end-to-end delay control is within 1.2ms
Extreme Environmental Testing
Passed the strict MIL-STD-810G military standard certification:
1. Vibration test: Scan frequency from 50Hz to 2000Hz without breaks
2. Waterproof performance: IP67 protection level for 1 hour continuous operation
3.Flexibility life: 50,000 times of 35° swaying test
